一种融合CNN与Transformer的高鲁棒性目标跟踪算法

doi:10.16182/j.issn1004731x.joss.23-0833

摘要/Abstract

摘要：

针对因目标物体形变、尺度变化、快速运动和遮挡等导致目标跟踪算法性能下降的问题，基于孪生网络架构提出了一种融合CNN与Transformer的高鲁棒性目标跟踪算法。在特征提取阶段，使用标准卷积提取浅层局部特征信息，在深层网络中设计了一种类卷积Transformer模块建模全局信息，并采用滑窗方式计算Transformer中的像素值，大大降低了计算量。在特征聚合阶段，采用多头交叉注意力模块构建特征增强与聚合网络，滤除干扰信息，突出与模板相关的信息以提高特征的判别性。与目前的主流算法相比，所提算法在OTB2015数据集上的形变、尺度变化、快速运动和遮挡4种不同挑战下的评估指标均为最优。在GOT-10K数据集上的平均重叠度为70.8%，相比TransT和SiamR-CNN算法分别提高3.7%和5.9%。在LaSOT、UAV123数据集上成功率分别为67.7%、71.9%，相比TransT和SiamR-CNN算法分别提高2.8%、2.8%和2.9%、7%。在VOT2018和VOT2019数据集上的鲁棒性评估结果，所提算法跟踪失败次数最少，鲁棒性指标得分分别为0.112和0.266，相比Ocean算法分别提高0.5%和5%，进一步验证了所提算法具有更高鲁棒性。

关键词: 目标跟踪, 孪生网络, Transformer, 多头交叉注意力机制, 高鲁棒性

Abstract:

To address the performance degradation of target tracking algorithms caused by target object deformation, scale variation, fast motion, and occlusion, a highly robust target tracking algorithm that Merging a CNN and Transformer is proposed based on siamese network architecture. In the feature extraction stage, standard convolutions are employed to extract shallow local feature information, while a convolution-like Transformer module is designed in the deep network to model global information. The pixel values in the Transformer are computed using a sliding window significantly reducing computational complexity. In the feature aggregation stage, a multi-head cross-attention module is utilized to construct a network for feature enhancement and aggregation. This module filters outirrelevant information and highlights the template-related information to improve the discriminative power of the features. Compared with the current mainstream algorithms, the proposed algorithm is optimal in terms of evaluation metrics under four different challenges of deformation, scale variation, fast motion and occlusion, on OTB2015 dataset. The average overlap(AO) on GOT-10K dataset is 70.8%, which is an improvement of 3.7% and 5.9% compared to the TransT and SiamR-CNN algorithms, respectively. The success rate on LaSOT and UAV123 dataset is 67.7% and 71.9%, which is improved by 2.8%, 2.8% and 2.9% and 7% compared to TransT and SiamR-CNN algorithms, respectively. The robustness(R) evaluation results on the VOT2018 and VOT2019 datasets show that the proposed algorithm achieved the least tracking failures rate, with robustness(R) index scores of 0.112 and 0.266, respectively, which are improved by 0.5% and 5% compared to Ocean algorithm, further verifies the higher robustness of the proposed algorithm.

Key words: object tracking, siamese network, Transformer, multi-head cross-attention mechanism, high robustness

中图分类号:

TP391.9

刘沛津,付雪峰,孙浩峰等 . 一种融合CNN与Transformer的高鲁棒性目标跟踪算法[J]. 系统仿真学报, 2024, 36(8): 1854-1868.

Liu Peijin,Fu Xuefeng,Sun Haofeng,et al . A Highly Robust Target Tracking Algorithm Merging CNN and Transformer[J]. Journal of System Simulation, 2024, 36(8): 1854-1868.

图/表 16

图1

表1

图2

图3

图4

图5

图6

图7

图8

表2

表3

图9

图10

图11

图12

表4

参考文献 36

1	张思贤, 杨艺, 张猛, 等. 高效的多特征自适应相关滤波跟踪器[J]. 系统仿真学报, 2022, 34(8): 1864-1873.
	Zhang Sixian, Yang Yi, Zhang Meng, et al. An Efficient Tracker via Multi-feature Adaptive Correlation Filter[J]. Journal of System Simulation, 2022, 34(8): 1864-1873.
2	周维, 刘宇翔, 廖广平, 等. 结合交并比损失的孪生网络目标跟踪算法研究[J]. 系统仿真学报, 2022, 34(9): 1956-1967.
	Zhou Wei, Liu Yuxiang, Liao Guangping, et al. Siamese Object Tracking Algorithm Combined with the Intersection over Union Loss[J]. Journal of System Simulation, 2022, 34(9): 1956-1967.
3	Danelljan Martin, Häger Gustav, Fahad Shahbaz Khan, et al. Accurate Scale Estimation for Robust Visual Tracking[C]//Proceedings British Machine Vision Conference 2014. Durham: BMVA Press, 2014: 1-11.
4	Lukežic Alan, Vojír Tomáš, Luka Cehovin Zajc, et al. Discriminative Correlation Filter with Channel and Spatial Reliability[C]//2017 IEEE Conference on Computer Vision and Pattern Recognition (CVPR). Piscataway: IEEE, 2017: 4847-4856.
5	Danelljan Martin, Häger Gustav, Fahad Shahbaz Khan, et al. Discriminative Scale Space Tracking[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2017, 39(8): 1561-1575.
6	Henriques João F, Rui Caseiro, Martins Pedro, et al. High-speed Tracking with Kernelized Correlation Filters[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2015, 37(3): 583-596.
7	李玺, 查宇飞, 张天柱, 等. 深度学习的目标跟踪算法综述[J]. 中国图象图形学报, 2019, 24(12): 2057-2080.
	Li Xi, Zha Yufei, Zhang Tianzhu, et al. Survey of Visual Object Tracking Algorithms Based on Deep Learning[J]. Journal of Image and Graphics, 2019, 24(12): 2057-2080.
8	Bertinetto L, Valmadre J, Henriques João F, et al. Fully-convolutional Siamese Networks for Object Tracking[C]//Computer Vision-ECCV 2016 Workshops. Cham: Springer International Publishing, 2016: 850-865.
9	Ren Shaoqing, He Kaiming, Girshick R, et al. Faster R-CNN: Towards Real-time Object Detection with Region Proposal Networks[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2017, 39(6): 1137-1149.
10	Li Bo, Yan Junjie, Wu Wei, et al. High Performance Visual Tracking with Siamese Region Proposal Network[C]//2018 IEEE/CVF Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2018: 8971-8980.
11	Li Bo, Wu Wei, Wang Qiang, et al. SiamRPN++: Evolution of Siamese Visual Tracking with Very Deep Networks[C]//2019 IEEE/CVF Conference on Computer Vision and Pattern Recognition (CVPR). Piscataway: IEEE, 2019: 4277-4286.
12	He Kaiming, Zhang Xiangyu, Ren Shaoqing, et al. Deep Residual Learning for Image Recognition[C]//2016 IEEE Conference on Computer Vision and Pattern Recognition (CVPR). Piscataway: IEEE, 2016: 770-778.
13	Jiang Borui, Luo Ruixuan, Mao Jiayuan, et al. Acquisition of Localization Confidence for Accurate Object Detection[C]//Computer Vision-ECCV 2018. Cham: Springer International Publishing, 2018: 816-832.
14	Zhang Zhipeng, Peng Houwen. Deeper and Wider Siamese Networks for Real-time Visual Tracking[C]//2019 IEEE/CVF Conference on Computer Vision and Pattern Recognition (CVPR). Piscataway: IEEE, 2019: 4586-4595.
15	Vaswani A, Shazeer N, Parmar N, et al. Attention Is All You Need[C]//Proceedings of the 31st International Conference on Neural Information Processing Systems. Red Hook: Curran Associates Inc., 2017: 6000-6010.
16	Dosovitskiy A, Beyer L, Kolesnikov A, et al. An Image is Worth 16x16 Words: Transformers for Image Recognition at Scale[EB/OL]. (2021-06-03) [2023-07-01]. .
17	Chen Xin, Yan Bin, Zhu Jiawen, et al. Transformer Tracking[C]//2021 IEEE/CVF Conference on Computer Vision and Pattern Recognition (CVPR). Piscataway: IEEE, 2021: 8122-8131.
18	王春雷, 张建林, 李美惠, 等. 结合卷积Transformer的目标跟踪算法[J]. 计算机工程, 2023, 49(4): 281-288, 296.
	Wang Chunlei, Zhang Jianlin, Li Meihui, et al. Object Tracking Algorithm Combining Convolution and Transformer[J]. Computer Engineering, 2023, 49(4): 281-288, 296.
19	Woo Sanghyun, Park Jongchan, Lee J Y, et al. CBAM: Convolutional Block Attention Module[C]//Computer Vision-ECCV 2018. Cham: Springer International Publishing, 2018: 3-19.
20	Lin T Y, Maire M, Belongie S, et al. Microsoft COCO: Common Objects in Context[C]//Computer Vision-ECCV 2014. Cham: Springer International Publishing, 2014: 740-755.
21	Huang Lianghua, Zhao Xin, Huang Kaiqi. GOT-10k: A Large High-diversity Benchmark for Generic Object Tracking in the Wild[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 2021, 43(5): 1562-1577.
22	Fan Heng, Lin Liting, Yang Fan, et al. LaSOT: A High-quality Benchmark for Large-scale Single Object Tracking[C]//2019 IEEE/CVF Conference on Computer Vision and Pattern Recognition (CVPR). Piscataway: IEEE, 2019: 5369-5378.
23	Müller Matthias, Bibi Adel, Giancola Silvio, et al. TrackingNet: A Large-scale Dataset and Benchmark for Object Tracking in the Wild[C]//Computer Vision-ECCV 2018: 15th European Conference, Munich, Germany, September 8-14, 2018, Proceedings, Part I. Heidelberg: Springer-Verlag, 2018: 310-327.
24	Wu Yi, Lim Jongwoo, Yang Ming. Online Object Tracking: A Benchmark[C]//2013 IEEE Conference on Computer Vision and Pattern Recognition. Piscataway: IEEE, 2013: 2411-2418.
25	Kristan Matej, Leonardis Aleš, Matas Jiří, et al. The Sixth Visual Object Tracking VOT2018 Challenge Results[C]//Computer Vision-ECCV 2018 Workshops. Cham: Springer International Publishing, 2019: 3-53.
26	Kristan Matej, Matas Jirí, Leonardis Aleš, et al. The Seventh Visual Object Tracking VOT2019 Challenge Results[C]//2019 IEEE/CVF International Conference on Computer Vision Workshop (ICCVW). Piscataway: IEEE, 2019: 2206-2241.
27	Mueller Matthias, Smith Neil, Ghanem Bernard. A Benchmark and Simulator for UAV Tracking[C]//Computer Vision-ECCV 2016. Cham: Springer International Publishing, 2016: 445-461.
28	Galoogahi H K, Fagg A, Huang Chen, et al. Need for Speed: A Benchmark for Higher Frame Rate Object Tracking[C]//2017 IEEE International Conference on Computer Vision (ICCV). Piscataway: IEEE, 2017: 1134-1143.
29	Loshchilov Ilya, Hutter Frank. Decoupled Weight Decay Regularization[EB/OL]. (2019-01-04) [2023-01-10]. .
30	Zhang Zhipeng, Peng Houwen, Fu Jianlong, et al. Ocean: Object-aware Anchor-free Tracking[C]//Computer Vision-ECCV 2020. Cham: Springer International Publishing, 2020: 771-787.
31	Voigtlaender Paul, Luiten J, Torr P H S, et al. Siam R-CNN: Visual Tracking by Re-detection[C]//2020 IEEE/CVF Conference on Computer Vision and Pattern Recognition (CVPR). Piscataway: IEEE, 2020: 6577-6587.
32	Bhat Goutam, Danelljan Martin, Luc Van Gool, et al. Learning Discriminative Model Prediction for Tracking[C]//2019 IEEE/CVF International Conference on Computer Vision (ICCV). Piscataway: IEEE, 2019: 6181-6190.
33	Zhu Zheng, Wang Qiang, Li Bo, et al. Distractor-aware Siamese Networks for Visual Object Tracking[C]//Computer Vision-ECCV 2018. Cham: Springer International Publishing, 2018: 103-119.
34	Danelljan Martin, Bhat Goutam, Fahad Shahbaz Khan, et al. ATOM: Accurate Tracking by Overlap Maximization[C]//2019 IEEE/CVF Conference on Computer Vision and Pattern Recognition (CVPR). Piscataway: IEEE, 2019: 4655-4664.
35	Chen Zedu, Zhong Bineng, Li Guorong, et al. Siamese Box Adaptive Network for Visual Tracking[C]//2020 IEEE/CVF Conference on Computer Vision and Pattern Recognition (CVPR). Piscataway: IEEE, 2020: 6667-6676.
36	Zhang Gang, Li Ziyi, Li Jianmin, et al. CFNet: Cascade Fusion Network for Dense Prediction[EB/OL]. (2023-10-31) [2022-07-01]. .

层结构	输出通道	模板图像大小	搜索图像大小
Parameters (M)	4.98
输入图像		128×128	256×256
3×3卷积	16	64×64	128×128
倒残差模块	32	64×64	128×128
倒残差模块，下采样	64	32×32	64×64
倒残差模块	64	32×32	64×64
倒残差模块，下采样	128	16×16	32×32
类卷积Transformer模块，N=2	128	16×16	32×32
倒残差模块，下采样	256	8×8	16×16
类卷积Transformer模块，N=4	256	8×8	16×16
倒残差模块，下采样	320	4×4	8×8
类卷积Transformer模块，N=3	320	4×4	8×8
1×1卷积	1 024	4×4	8×8

算法	VOT2018			VOT2019
算法	EAO↑	A↑	R↓	EAO↑	A↑	R↓
Ours	0.490	0.617	0.112	0.357	0.578	0.266
Ocean	0.489	0.592	0.117	0.350	0.594	0.316
SiamBAN	0.452	0.597	0.178	0.327	0.602	0.396
DiMP	0.440	0.597	0.153	0.379	0.594	0.278
SiamRPN++	0.414	0.600	0.234	0.292	0.580	0.446
SiamR-CNN	0.408	0.609	0.220	—	—	—
ATOM	0.401	0.590	0.204	0.301	0.603	0.411
DaSiamRPN	0.383	0.586	0.276	—	—	—
SiamFC	0.188	0.503	0.585	—	—	—

算法	GOT-10k			LaSOT		OTB2015		UAV123	NFS/(30帧/s)
算法	AO	SR_0.5	SR_0.75	AUC	P	AUC	P	AUC	AUC
Ours	70.8	82.4	65.8	67.7	70.2	71.1	92.2	71.9	65.5
TransT	67.1	76.8	60.9	64.9	69.0	69.4	—	69.1	65.7
SiamR-CNN	64.9	72.8	59.7	64.8	68.4	70.1	89.1	64.9	63.9
Ocean	61.1	72.1	47.3	56.0	56.6	68.4	92.0	—	—
DiMP	61.1	71.7	49.2	56.9	56.7	68.4	90.2	65.3	62.0
ATOM	55.6	63.4	40.2	51.5	50.5	66.7	87.9	64.2	58.4
SiamBAN	—	—	—	51.4	52.1	69.6	91.0	63.1	59.4
SiamRPN++	51.7	61.6	32.5	49.6	49.1	69.6	91.5	61.3	50.2
DaSiamRPN	44.4	53.6	22.0	41.5	—	65.9	88.0	58.6	39.5
CFNet	43.4	48.1	19.0	27.5	25.9	56.8	74.8	43.6	—
SiamFC	34.8	35.3	9.8	33.6	33.9	58.2	77.1	46.1	—
fDSST	28.9	27.8	12.1	20.3	18.4	55.1	72.6	—	—

#	特征提取网络	特征聚合网络	精确率
#	特征提取网络	特征聚合网络	形变	尺度变化	快速运动	遮挡
1	ResNet50	ECA+CFA	88.1	91.7	89.2	86.2
2	ResNet50	MHCA	89.0(0.9↑)	92.8(1.1↑)	90.0(0.8↑)	87.2(1.0↑)
3	类卷积Transformer	ECA+CFA	89.4(1.3↑)	93.6(1.9↑)	90.9(1.7↑)	87.8(1.6↑)
4	类卷积Transformer	MHCA	89.7(1.6↑)	94.1(2.4↑)	91.5(2.3↑)	88.2(2.0↑)
