智能网联汽车计算卸载与边缘缓存联合优化策略

doi:10.16182/j.issn1004731x.joss.22-0147

系统仿真学报 ›› 2023, Vol. 35 ›› Issue (6): 1203-1214.doi: 10.16182/j.issn1004731x.joss.22-0147

智能网联汽车计算卸载与边缘缓存联合优化策略

丁飞¹^,²^,³(), 沙宇晨¹^,²(), 洪莹¹^,², 蒯晓¹^,², 张登银¹^,²^,³

^1.南京邮电大学物联网学院, 江苏南京 210003
^2.南京邮电大学江苏省宽带无线通信和物联网重点实验室, 江苏南京 210003
^3.南京邮电大学通信与网络技术国家工程研究中心, 江苏南京 210003

收稿日期:2022-03-01 修回日期:2022-04-25 出版日期:2023-06-29 发布日期:2023-06-20
通讯作者: 沙宇晨 E-mail:dingfei@njupt.edu.cn;554320330@qq.com
作者简介:丁飞(1981-)，男，副教授，博士，研究方向为物联网与信息系统、边缘智能与协同计算等。E-mail：dingfei@njupt.edu.cn
基金资助:
国家自然科学基金(61871446);江苏省重点研发计划(BE2020084-1);江苏省“六大人才高峰”高层次人才培养(DZXX-008);中国博士后科学基金面上资助项目(2019M661900);江苏省博士后科研资助计划(2019K026)

Joint Optimization Strategy of Computing Offloading and Edge Caching for Intelligent Connected Vehicles

Fei Ding¹^,²^,³(), Yuchen Sha¹^,²(), Ying Hong¹^,², Xiao Kuai¹^,², Dengyin Zhang¹^,²^,³

^1.School of Internet of things, Nanjing University of Posts and Telecommunications, Nanjing 210003, China
^2.Key Laboratory of Broadband Wireless Communication and Internet of Things of Jiangsu Province, Nanjing University of Posts and Telecommunications, Nanjing 210003, China
^3.National Engineering Research Center for Communication and Network Technology, Nanjing University of Posts and Telecommunications, Nanjing 210003, China

Received:2022-03-01 Revised:2022-04-25 Online:2023-06-29 Published:2023-06-20
Contact: Yuchen Sha E-mail:dingfei@njupt.edu.cn;554320330@qq.com

摘要/Abstract

摘要：

为了保障智能网联汽车的低时延通信，利用蜂窝车联网中V2X(vehicle to everything)信道模型、边缘计算技术，研究计算卸载与边缘缓存联合优化策略。设计了一种智能网联汽车计算卸载与边缘缓存协同模型L-DDPG(least-deep deterministic policy gradient)，通过对车载本地与边缘计算资源的整合，支持V2X场景下对不同计算任务的分类处理。由边缘平台对车载计算请求进行预判决，确保对连续的计算任务快速响应；结合基于最近最少使用(least recently used, LRU)的边缘缓存策略，实现对新计算任务的高效管理；基于DDPG算法对计算卸载与边缘缓存进行联合卸载决策。仿真结果表明：L-DDPG模型性能优于传统模型，能够有效提升系统的工作效能，在保障业务服务质量的同时降低时延和系统资源消耗。

关键词: 智能网联汽车, V2X(vehicle to everything), 多接入边缘计算, 深度强化学习, 计算卸载, 边缘缓存

Abstract:

To guarantee the low-delay communication of intelligent connected vehicles, the V2X channel model and the multi-access edge computing (MEC) technology, are used to carry out the research of the joint optimization strategy of computing offloading and edge caching. An intelligent connected vehicle with task offloading and edge caching model least-deep deterministic policy gradient(L-DDPG) is developed. By integrating the vehicular local and edge computing resources, the classification processing of different computing tasks in V2X scenarios is supported. The vehicular computing request is prejudged by edge platform to ensure the rapid response of continuous homogeneous computing tasks. Combining with the least recently used strategy, the new computing tasks are efficiently managed. A joint offloading decision for computing offloading and edge caching is carried out based on deep deterministic policy gradient(DDPG) algorithm. Simulation results show that the performance of L-DDPG model is better than that of traditional models, which can effectively improve the system performance, ensure the service quality, and reduce the time delay and resource consumption.

Key words: intelligent connected vehicle, vehicle to everything(V2X), multi-access edge computing, deep reinforcement learning, computing offloading, edge caching

中图分类号:

TP393

丁飞, 沙宇晨, 洪莹, 蒯晓, 张登银. 智能网联汽车计算卸载与边缘缓存联合优化策略[J]. 系统仿真学报, 2023, 35(6): 1203-1214.

Fei Ding, Yuchen Sha, Ying Hong, Xiao Kuai, Dengyin Zhang. Joint Optimization Strategy of Computing Offloading and Edge Caching for Intelligent Connected Vehicles[J]. Journal of System Simulation, 2023, 35(6): 1203-1214.

图/表 10

图1

图2

图3

表1

仿真参数

参数	数值
RSU覆盖半径/m	300
车辆发射功率 $p v / d B m$	20
CPU能耗功率 $p c / W$	5
路侧边缘节点数	[3, 7]
单个MEC节点的计算能力 $f i m / G H z$	[5, 9]
上行传输信道数量 $K$	10
信道总带宽 $B / M H z$	20
高斯白噪声功率 $σ 2 / d B m$	-100
车辆计算能力 $f i v / G H z$	1
计算任务大小 $d i / M B$	20
权重因子 $α$	0.5
缓存空间 $H m / M B$	500
最大容忍时延 $t i m a x / s$	0.003
载波频率 $f c / G H z$	5.915
基站的高度 $h B S / m$	35
车辆的高度 $h U T / m$	1.5
发送信号功率 $P t x / d B m$	23
天线增益 $G a n t e n n a / d B i$	3
噪声功率 $P n o i s e / W$	$3 × 10 - 13$

表1

图4

图5

图6

图7

图8

图9
