订单可拆分的多目标混合流水车间调度研究

doi:10.16182/j.issn1004731x.joss.25-0745

摘要/Abstract

摘要：

针对订单可拆分的多目标混合流水车间调度问题(order splitting multi-objective hybrid flow-shop scheduling problem， OSMOHFSP)，构建了以最小化最大完工时间和订单总延迟为双目标的优化模型。引入固定子批规格约束以反映实际生产中常见的拆分限制。设计了一种基于子批规格候选集合的子批生成策略，用于高效筛选可行拆分组合，有效压缩搜索空间维度与计算复杂度。提出融合NSGA-II与SA的混合多目标元启发式算法，通过构造2种交叉与4种变异算子增强全局搜索能力，嵌入多种邻域策略、Pareto自适应接受准则与Pareto归档机制的改进SA，用于挖掘拆分方案与调度序列协同优化的潜能，引入改进的拥挤距离计算与精英保留策略以保障解集多样性与优质个体传承。仿真实验结果显示所提算法在求解OSMOHFSP时相较对比算法表现出更好的收敛性、多样性和支配优势。

关键词: 订单可拆分, 多目标优化, 混合流水车间调度, 最大完工时间, 订单总延迟, NSGA-II, SA

Abstract:

To address the order splitting multi-objective hybrid flow-shop scheduling problem (OSMOHFSP), a dual-objective optimization model was formulated with the objectives of minimizing makespan and total order tardiness. Fixed sub-batch specification constraints were incorporated to reflect common splitting limitations in actual production. A sub-batch generation strategy based on a candidate set of sub-batch specifications was designed to efficiently filter feasible splitting combinations, effectively reducing the search space dimensionality and computational complexity. A hybrid multi-objective metaheuristic algorithm integrating NSGA-II and SA was proposed. The global search capability was enhanced by constructing two crossover and four mutation operators. An improved SA embedding multiple neighborhood strategies, a Pareto-adaptive acceptance criterion, and a Pareto archiving mechanism was incorporated to explore the co-optimization potential of splitting schemes and scheduling sequences. Furthermore, an improved crowding distance calculation and an elite retention strategy were introduced to ensure the diversity of the solution set and the inheritance of high-quality individuals. Simulation experiment results indicate that the proposed algorithm exhibits better convergence, diversity, and dominance advantage than the comparative algorithms in solving the OSMOHFSP.

Key words: order splitting, multi-objective optimization, hybrid flow-shop scheduling, makespan, total order tardiness, NSGA-II, SA

中图分类号:

TP301.6

于俊杰,吉卫喜,陈琛等 . 订单可拆分的多目标混合流水车间调度研究[J]. 系统仿真学报, 2026, 38(7): 2020-2036.

Yu Junjie,Ji Weixi,Chen Chen,et al . Research on Multi-objective Hybrid Flow-shop Scheduling with Order Splitting[J]. Journal of System Simulation, 2026, 38(7): 2020-2036.

图/表 13

表1

模型符号定义

符号	定义
i, a	订单索引
j, b	子批索引
k	阶段、工序索引
l	机器索引
h, c	速度索引
n	订单总数
p_i	订单i的子批总数
Q_i	订单i的总需求量
s	阶段总数
m_k	阶段k的机器数量
v_l	机器l的速度总数
q_ij	订单i的子批j的批量
O_ijk	订单i的子批j的第k道工序
$T i C$	订单i的完工时间
$T i j k S$	O_ijk 的加工开始时间
$T i j k C$	O_ijk 的加工结束时间
D_i	订单i的截止日期
t_ijklh	工序O_ijk 在机器l上以h速度的加工时间
w_ijkl	0-1变量，若工序O_ijk 能在机器l上加工，其值为1，否则为0
u_ijkl	0-1变量，若工序O_ijk 在机器l上加工，其值为1，否则为0
x_ijklh	0-1变量，若工序O_ijk 在机器l上以h的速度加工，其值为1，否则为0
y_ijkabkl	0-1变量，若工序O_ijk 先于工序O_abk 在机器l上加工，其值为1，否则为0
z_ij	0-1变量，若订单i的子批j的批量非0(q_ij ≥1)，其值为1，否则为0
E	一个很大的正数

表1

图1

图2

图3

图4

图5

图6

表2

图7

表3

表4

各算法在测试集上的RDI和HV结果

组号	算例规模	NSGA-II		NSTLBO		MOPSO		NSLSO		NSGA-II-SA
组号	算例规模	RDI/%	HV	RDI/%	HV	RDI/%	HV	RDI/%	HV	RDI/%	HV
平均		26.30	4.56×10⁸	163.21	1.07×10⁷	150.97	2.03×10⁷	110.75	8.41×10⁷	8.40	5.64×10⁸
1	10×2×3×3	23.67	4.75×10⁶	137.95	4.55×10⁵	113.36	8.72×10⁵	91.03	1.69×10⁶	5.97	5.76×10⁶
2	10×2×3×5	20.63	2.01×10⁶	135.33	1.79×10⁵	121.57	3.16×10⁵	81.49	8.35×10⁵	7.05	2.38×10⁶
3	10×2×5×3	23.32	6.24×10⁶	142.44	3.65×10⁵	126.23	8.90×10⁵	89.40	2.19×10⁶	8.87	7.28×10⁶
4	10×2×5×5	21.52	4.49×10⁶	148.21	3.27×10⁵	131.33	6.67×10⁵	87.06	1.82×10⁶	8.89	5.05×10⁶
5	10×4×3×3	32.07	9.22×10⁶	150.99	6.35×10⁵	138.49	1.06×10⁶	104.60	2.96×10⁶	8.81	1.19×10⁷
6	10×4×3×5	27.26	5.42×10⁶	147.50	4.68×10⁵	139.64	5.99×10⁵	101.13	1.78×10⁶	6.56	6.82×10⁶
7	10×4×5×3	22.77	2.71×10⁷	162.79	1.37×10⁶	148.92	2.45×10⁶	97.02	9.55×10⁶	9.69	3.11×10⁷
8	10×4×5×5	24.43	1.12×10⁷	158.69	5.86×10⁵	146.10	1.04×10⁶	95.39	4.16×10⁶	9.49	1.33×10⁷
9	10×8×3×3	33.57	2.27×10⁷	166.20	9.95×10⁵	151.71	1.97×10⁶	111.76	6.96×10⁶	8.02	3.08×10⁷
10	10×8×3×5	24.52	9.95×10⁶	151.65	7.83×10⁵	136.72	1.26×10⁶	94.84	3.49×10⁶	5.84	1.22×10⁷
11	10×8×5×3	24.62	2.97×10⁷	168.31	1.08×10⁶	155.46	2.06×10⁶	110.48	7.67×10⁶	9.15	3.53×10⁷
12	10×8×5×5	23.99	2.28×10⁷	163.66	1.21×10⁶	148.57	1.99×10⁶	99.60	7.55×10⁶	9.24	2.70×10⁷
13	20×2×3×3	24.21	3.27×10⁷	148.38	2.51×10⁶	139.71	3.02×10⁶	99.93	1.08×10⁷	6.97	3.90×10⁷
14	20×2×3×5	19.53	2.04×10⁷	151.68	1.22×10⁶	130.96	2.92×10⁶	91.54	7.29×10⁶	5.39	2.35×10⁷
15	20×2×5×3	21.14	6.70×10⁷	159.77	3.13×10⁶	151.21	5.30×10⁶	109.27	1.73×10⁷	7.49	7.73×10⁷
16	20×2×5×5	21.07	2.82×10⁷	158.81	1.56×10⁶	143.09	3.01×10⁶	105.18	8.13×10⁶	8.91	3.17×10⁷
17	20×4×3×3	30.15	6.65×10⁷	156.04	4.33×10⁶	153.18	4.65×10⁶	106.05	2.02×10⁷	8.50	8.55×10⁷
18	20×4×3×5	26.59	4.00×10⁷	160.47	2.73×10⁶	149.58	3.48×10⁶	106.75	1.18×10⁷	7.96	5.00×10⁷
19	20×4×5×3	26.25	1.78×10⁸	168.90	6.03×10⁶	154.70	1.32×10⁷	115.24	4.38×10⁷	10.93	2.11×10⁸
20	20×4×5×5	22.19	8.10×10⁷	170.07	2.66×10⁶	155.96	5.58×10⁶	107.86	2.22×10⁷	9.77	9.29×10⁷
21	20×8×3×3	33.70	1.92×10⁸	173.62	5.68×10⁶	154.37	1.70×10⁷	122.69	4.44×10⁷	10.76	2.45×10⁸
22	20×8×3×5	31.95	8.27×10⁷	172.72	3.35×10⁶	157.93	6.34×10⁶	115.22	2.24×10⁷	8.44	1.06×10⁸
23	20×8×5×3	31.89	2.79×10⁸	179.46	4.85×10⁶	169.86	9.55×10⁶	120.30	6.39×10⁷	10.23	3.53×10⁸
24	20×8×5×5	26.22	1.67×10⁸	172.16	5.25×10⁶	162.64	8.64×10⁶	119.69	3.79×10⁷	8.98	2.01×10⁸
25	50×2×3×3	27.11	3.31×10⁸	157.69	1.77×10⁷	147.00	2.93×10⁷	111.81	8.61×10⁷	6.55	4.09×10⁸
26	50×2×3×5	29.03	1.57×10⁸	162.92	7.86×10⁶	152.31	1.21×10⁷	112.58	4.30×10⁷	8.47	1.97×10⁸
27	50×2×5×3	21.74	8.28×10⁸	171.63	2.08×10⁷	159.28	4.67×10⁷	124.17	1.56×10⁸	9.04	9.46×10⁸
28	50×2×5×5	16.94	3.32×10⁸	168.76	1.06×10⁷	160.00	1.72×10⁷	122.46	6.20×10⁷	7.46	3.69×10⁸
29	50×4×3×3	31.78	1.22×10⁹	175.26	2.69×10⁷	163.66	6.09×10⁷	125.10	2.56×10⁸	6.99	1.59×10⁹
30	50×4×3×5	28.90	4.18×10⁸	169.56	1.48×10⁷	162.55	2.01×10⁷	127.17	7.95×10⁷	8.14	5.21×10⁸
31	50×4×5×3	28.84	1.76×10⁹	174.21	3.82×10⁷	169.18	5.87×10⁷	128.43	3.07×10⁸	10.61	2.12×10⁹
32	50×4×5×5	27.06	9.26×10⁸	176.02	2.18×10⁷	164.65	4.03×10⁷	124.32	1.86×10⁸	9.25	1.12×10⁹
33	50×8×3×3	34.51	1.95×10⁹	178.12	3.92×10⁷	169.20	6.98×10⁷	133.34	3.29×10⁸	7.70	2.61×10⁹
34	50×8×3×5	32.93	9.67×10⁸	176.38	2.39×10⁷	169.37	3.79×10⁷	130.96	1.72×10⁸	10.47	1.23×10⁹
35	50×8×5×3	28.19	4.11×10⁹	180.90	7.00×10⁷	171.39	1.46×10⁸	132.39	6.67×10⁸	8.78	5.06×10⁹
36	50×8×5×5	22.43	2.05×10⁹	178.43	4.12×10⁷	164.96	9.52×10⁷	130.91	3.24×10⁸	7.04	2.42×10⁹

表4

表5

图8

参考文献 50

[1]	Mendoza-Mendoza Adel, Ospino-Castro Wilfrido, Romero-Martínez Daniela. Production Scheduling in a Flexible Hybrid Flow Shop in the Food Industry Based on the Theory of Constraints[J]. International Journal of Engineering Research in Africa, 2021, 52: 124-136.
[2]	Mariappan Kadarkarainadar Marichelvam, Prabaharan Thirumoorthy, Yang Xinshe. A Discrete Firefly Algorithm for the Multi-objective Hybrid Flowshop Scheduling Problems[J]. IEEE Transactions on Evolutionary Computation, 2014, 18(2): 301-305.
[3]	Cao Jianhua, Pan Ruilin, Xia Xue, et al. An Efficient Scheduling Approach for an Iron-steel Plant Equipped with Self-generation Equipment Under Time-of-use Electricity Tariffs[J]. Swarm and Evolutionary Computation, 2021, 60: 100764.
[4]	Tliba Khalil, M L Diallo Thierno, Penas Olivia, et al. Digital Twin-driven Dynamic Scheduling of a Hybrid Flow Shop[J]. Journal of Intelligent Manufacturing, 2023, 34(5): 2281-2306.
[5]	Wang Shijin, Wang Xiaodong, Chu Feng, et al. An Energy-efficient Two-stage Hybrid Flow Shop Scheduling Problem in a Glass Production[J]. International Journal of Production Research, 2020, 58(8): 2283-2314.
[6]	Liu Ming, Yang Xuenan, Chu Feng, et al. Energy-oriented Bi-objective Optimization for the Tempered Glass Scheduling[J]. Omega, 2020, 90: 101995.
[7]	Li Ronghao, Li Junqing, Li Jiake, et al. A Dimension-aware Gaining-sharing Knowledge Algorithm for Distributed Hybrid Flowshop Scheduling with Resource-dependent Processing Time[J]. Complex & Intelligent Systems, 2024, 10(5): 6051-6080.
[8]	李颖俐, 李新宇, 高亮. 混合流水车间调度问题研究综述[J]. 中国机械工程, 2020, 31(23): 2798-2813, 2828.
	Li Yingli, Li Xinyu, Gao Liang. Review on Hybrid Flow Shop Scheduling Problems[J]. China Mechanical Engineering, 2020, 31(23): 2798-2813, 2828.
[9]	Luo Lin, Yan Xuesong. Selection Hyperheuristic with Knowledge-based Q-learning for Dynamic Distributed Hybrid Flow Shop Scheduling Problem Considering Operation Inspection[J]. Swarm and Evolutionary Computation, 2025, 95: 101936.
[10]	Feng Yingjie, Kong Jili. Multi-objective Hybrid Flow-shop Scheduling in Parallel Sequential Mode While Considering Handling Time and Setup Time[J]. Applied Sciences, 2023, 13(6): 3563.
[11]	Huang Hui, Luo Bin, Wang Zhongning, et al. Improved MOMVO Algorithm to Solve the Multi-objective HFSP Considering Machine Shutdown[J]. Journal of Physics: Conference Series, 2021, 1873(1): 012049.
[12]	Kurt A. Integrating Sequence-dependent Setup Times and Blocking in Hybrid Flow Shop Scheduling to Minimize Total Tardiness[J]. International Journal of Industrial Engineering Computations, 2025, 16(1): 147-158.
[13]	Wang Yijian, Wang Gaige, Wang Ling. A Tree-based Multiobjective Evolutionary Algorithm for Energy-efficient Hybrid Flow-shop Scheduling[J]. IEEE Transactions on Evolutionary Computation, 2025, 29(6): 2313-2327.
[14]	轩华, 吕琳, 李冰. 考虑组合缓冲的分布式异构混合流水车间调度[J]. 系统仿真学报, 2025, 37(10): 2672-2686.
	Xuan Hua, Lin Lü, Li Bing. Distributed Heterogeneous Hybrid Flow-shop Scheduling Considering Combined Buffer[J]. Journal of System Simulation, 2025, 37(10): 2672-2686.
[15]	Öztop Hande, Fatih Tasgetiren M, Kandiller Levent, et al. Ensemble of Metaheuristics for Energy-efficient Hybrid Flowshops: Makespan Versus Total Energy Consumption[J]. Swarm and Evolutionary Computation, 2020, 54: 100660.
[16]	Bozorgirad M A, Logendran R. A Comparison of Local Search Algorithms with Population-based Algorithms in Hybrid Flow Shop Scheduling Problems with Realistic Characteristics[J]. The International Journal of Advanced Manufacturing Technology, 2016, 83(5): 1135-1151.
[17]	Chen T L, Cheng Chenyang, Yihan Chou. Multi-objective Genetic Algorithm for Energy-efficient Hybrid Flow Shop Scheduling with Lot Streaming[J]. Annals of Operations Research, 2020, 290(1): 813-836.
[18]	Fan Jiaxin, Li Yingli, Xie Jin, et al. A Hybrid Evolutionary Algorithm Using Two Solution Representations for Hybrid Flow-shop Scheduling Problem[J]. IEEE Transactions on Cybernetics, 2023, 53(3): 1752-1764.
[19]	Fattahi Parviz, Seyed Mohammad Hassan Hosseini, Jolai Fariborz, et al. A Branch and Bound Algorithm for Hybrid Flow Shop Scheduling Problem with Setup Time and Assembly Operations[J]. Applied Mathematical Modelling, 2014, 38(1): 119-134.
[20]	Dabiri Mohamadreza, Yazdani Mehdi, Naderi Bahman, et al. Modeling and Solution Methods for Hybrid Flow Shop Scheduling Problem with Job Rejection[J]. Operational Research, 2022, 22(3): 2721-2765.
[21]	Tang L, Xuan H. Lagrangian Relaxation Algorithms for Real-time Hybrid Flowshop Scheduling with Finite Intermediate Buffers[J]. Journal of the Operational Research Society, 2006, 57(3): 316-324.
[22]	Guinet A G P, Solomon M M. Scheduling Hybrid Flowshops to Minimize Maximum Tardiness or Maximum Completion Time[J]. International Journal of Production Research, 1996, 34(6): 1643-1654.
[23]	Dios Manuel, Fernandez-Viagas Victor, Framinan Jose M. Efficient Heuristics for the Hybrid Flow Shop Scheduling Problem with Missing Operations[J]. Computers & Industrial Engineering, 2018, 115: 88-99.
[24]	Gupta J N D, Tunc E A. Minimizing Tardy Jobs in a Two-stage Hybrid Flowshop[J]. International Journal of Production Research, 1998, 36(9): 2397-2417.
[25]	Yan Jihong, Li Lin, Zhao Fu, et al. A Multi-level Optimization Approach for Energy-efficient Flexible Flow Shop Scheduling[J]. Journal of Cleaner Production, 2016, 137: 1543-1552.
[26]	Liao Ching-Jong, Tjandradjaja Evi, Chung Tsui-Ping. An Approach Using Particle Swarm Optimization and Bottleneck Heuristic to Solve Hybrid Flow Shop Scheduling Problem[J]. Applied Soft Computing, 2012, 12(6): 1755-1764.
[27]	秦红斌, 李晨晓, 唐红涛, 等. 基于MOMA的可重入混合流水车间调度问题研究[J]. 系统仿真学报, 2024, 36(1): 131-148.
	Qin Hongbin, Li Chenxiao, Tang Hongtao, et al. Reentrant Hybrid Flow Shop Scheduling Problem Based on MOMA[J]. Journal of System Simulation, 2024, 36(1): 131-148.
[28]	温廷新, 关婷誉. 考虑能耗和运输的有限缓冲区混合流水车间调度[J]. 系统仿真学报, 2024, 36(6): 1344-1358.
	Wen Tingxin, Guan Tingyu. Hybrid Flow Shop Scheduling with Limited Buffers Considering Energy Consumption and Transportation[J]. Journal of System Simulation, 2024, 36(6): 1344-1358.
[29]	马训德, 毕利, 王俊杰. 基于群体免疫算法的绿色车间调度研究[J]. 系统仿真学报, 2024, 36(11): 2578-2591.
	Ma Xunde, Bi Li, Wang Junjie. Research on Green Job Shop Scheduling Based on Herd Immunity Optimizer[J]. Journal of System Simulation, 2024, 36(11): 2578-2591.
[30]	Zhou Binghai, Liu Wenlong. Energy-efficient Multi-objective Scheduling Algorithm for Hybrid Flow Shop with Fuzzy Processing Time[J]. Proceedings of the Institution of Mechanical Engineers, Part I: Journal of Systems and Control Engineering, 2019, 233(10): 1282-1297.
[31]	Zhang Wenqiang, Geng Huili, Li Chen, et al. Q-learning-based Multi-objective Particle Swarm Optimization with Local Search Within Factories for Energy-efficient Distributed Flow-shop Scheduling Problem[J]. Journal of Intelligent Manufacturing, 2025, 36(1): 185-208.
[32]	Neufeld Janis S, Schulz Sven, Buscher Udo. A Systematic Review of Multi-objective Hybrid Flow Shop Scheduling[J]. European Journal of Operational Research, 2023, 309(1): 1-23.
[33]	Zhu Huangqiu, Shi Yijian. Displacement Self-sensing Control of Permanent Magnet Assisted Bearingless Synchronous Reluctance Motor Based on Least Square Support Vector Machine Optimized by Improved NSGA-II[J]. IEEE Transactions on Industrial Electronics, 2024, 71(2): 1201-1211.
[34]	Verma Shanu, Pant Millie, Snasel Vaclav. A Comprehensive Review on NSGA-II for Multi-objective Combinatorial Optimization Problems[J]. IEEE Access, 2021, 9: 57757-57791.
[35]	Li Xinyu, Gao Liang. An Effective Hybrid Genetic Algorithm and Tabu Search for Flexible Job Shop Scheduling Problem[J]. International Journal of Production Economics, 2016, 174: 93-110.
[36]	Yu Junjie, Chen Chen, Zhang Jian, et al. Quantitative Study of Solid-state Mechanical Mixing by High-pressure Torsion Based on Image Processing[J]. Materials Today Communications, 2024, 39: 109126.
[37]	Yue Caitong, Suganthan P N, Liang Jing, et al. Differential Evolution Using Improved Crowding Distance for Multimodal Multiobjective Optimization[J]. Swarm and Evolutionary Computation, 2021, 62: 100849.
[38]	Hu Xiaomin, Zhang Shourong, Li Min, et al. Multimodal Particle Swarm Optimization for Feature Selection[J]. Applied Soft Computing, 2021, 113, Part A: 113107887.
[39]	Yang Xunian, Hao Xiaochen, Yang Tianqi, et al. Elite-guided Multi-objective Cuckoo Search Algorithm Based on Crossover Operation and Information Enhancement[J]. Soft Computing, 2023, 27(8): 4761-4778.
[40]	Ma Haiping, Zhang Yajing, Sun Shengyi, et al. A Comprehensive Survey on NSGA-II for Multi-objective Optimization and Applications[J]. Artificial Intelligence Review, 2023, 56(12): 15217-15270.
[41]	Venkata Rao Ravipudi. Jaya: An Advanced Optimization Algorithm and Its Engineering Applications[M]. Cham: Springer International Publishing, 2019: 13-16.
[42]	Coello Coello C A, Lechuga M S. MOPSO: A Proposal for Multiple Objective Particle Swarm Optimization[C]//Proceedings of the 2002 Congress on Evolutionary Computation. CEC' 02. Piscataway: IEEE, 2002: 1051-1056.
[43]	Karimi N, Davoudpour H. Multi-objective Colonial Competitive Algorithm for Hybrid Flowshop Problem[J]. Applied Soft Computing, 2016, 49: 725-733.
[44]	Lei Deming, Zheng Youlian. Hybrid Flow Shop Scheduling with Assembly Operations and Key Objectives: A Novel Neighborhood Search[J]. Applied Soft Computing, 2017, 61: 122-128.
[45]	Liu Chenfei, Qiang Cheng, Cheng Chenyang, et al. Enhancing Energy Efficiency in Distributed Hybrid Forging Flow-shops: A Novel Scheduling Approach to Capitalise on Residual Forging Heat[J]. International Journal of Production Research, 2025, 63(6): 2170-2189.
[46]	Potts C N, Van Wassenhove L N. A Decomposition Algorithm for the Single Machine Total Tardiness Problem[J]. Operations Research Letters, 1982, 1(5): 177-181.
[47]	Taillard E. Benchmarks for Basic Scheduling Problems[J]. European Journal of Operational Research, 1993, 64(2): 278-285.
[48]	Pan Quanke, Ruiz Rubén, Alfaro-Fernández Pedro. Iterated Search Methods for Earliness and Tardiness Minimization in Hybrid Flowshops with Due Windows[J]. Computers & Operations Research, 2017, 80: 50-60.
[49]	Yu Fei, Gao Liang, Lu Chao, et al. A Learning-based Hybrid Artificial Bee Colony Algorithm for Energy-efficient Distributed Heterogeneous Type-2 Fuzzy Welding Shop Scheduling Problem with Factory Eligibility[J]. IEEE Transactions on Automation Science and Engineering, 2025, 22: 9934-9947.
[50]	Vallada Eva, Ruiz Rubén, Minella Gerardo. Minimising Total Tardiness in the M-machine Flowshop Problem: A Review and Evaluation of Heuristics and Metaheuristics[J]. Computers and Operations Research, 2008, 35(4): 1350-1373.

算例	算法①	算法②	算法③	算法④	算法⑤
5	121.09	39.18	44.04	36.98	30.64
9	143.16	48.03	37.44	33.30	28.78
10	155.04	38.02	41.02	35.48	26.80
11	126.84	76.51	74.04	63.71	61.89
12	174.41	92.15	63.72	67.16	59.15
18	139.52	76.99	73.71	73.23	37.16
22	131.65	49.70	57.95	27.50	24.77
23	141.94	79.49	59.69	63.90	29.85
26	95.11	49.84	48.97	29.62	9.38
29	143.49	42.13	60.83	41.52	18.16

组号	算例规模	Cov1	Cov1'	Cov2'	Cov3'	Cov4'	T₁/s	T₂/s	T₃/s	T₄/s	T₅/s
平均		0.04	0.91	1	1	1	456	1 025	303	683	533
1	10×2×3×3	0.02	0.95	1	1	1	76	168	45	106	92
2	10×2×3×5	0.07	0.87	1	1	1	65	145	39	91	79
3	10×2×5×3	0.09	0.83	1	1	1	106	245	66	154	127
4	10×2×5×5	0.14	0.73	1	1	1	134	306	83	193	166
5	10×4×3×3	0	0.97	1	1	1	99	224	61	143	120
6	10×4×3×5	0.02	0.98	1	1	1	95	215	59	136	113
7	10×4×5×3	0.09	0.82	1	1	1	189	431	118	274	228
8	10×4×5×5	0.07	0.88	1	1	1	169	380	104	252	204
9	10×8×3×3	0.02	0.95	1	1	1	178	397	110	259	213
10	10×8×3×5	0	0.99	1	1	1	172	395	110	253	205
11	10×8×5×3	0.08	0.86	1	1	1	282	639	177	407	340
12	10×8×5×5	0.08	0.80	1	1	1	329	744	210	479	398
13	20×2×3×3	0	1	1	1	1	94	207	56	131	114
14	20×2×3×5	0	0.93	1	1	1	68	152	42	96	81
15	20×2×5×3	0.05	0.88	1	1	1	95	213	59	135	114
16	20×2×5×5	0.09	0.81	1	1	1	81	180	50	115	98
17	20×4×3×3	0.01	0.95	1	1	1	95	214	60	137	114
18	20×4×3×5	0.01	0.95	1	1	1	91	206	58	130	109
19	20×4×5×3	0.10	0.85	1	1	1	177	397	111	254	212
20	20×4×5×5	0.09	0.88	1	1	1	159	361	102	232	190
21	20×8×3×3	0	1	1	1	1	388	864	246	559	463
22	20×8×3×5	0	0.99	1	1	1	383	860	247	560	446
23	20×8×5×3	0.05	0.89	1	1	1	633	1 421	408	926	747
24	20×8×5×5	0.10	0.88	1	1	1	727	1 643	482	1 088	864
25	50×2×3×3	0	0.99	1	1	1	207	464	129	295	248
26	50×2×3×5	0	1	1	1	1	224	499	144	320	267
27	50×2×5×3	0.11	0.85	1	1	1	484	1 063	296	680	581
28	50×2×5×5	0.13	0.71	1	1	1	575	1 294	364	829	685
29	50×4×3×3	0	1	1	1	1	746	1 664	479	1 092	887
30	50×4×3×5	0	0.98	1	1	1	744	1 648	478	1 085	876
31	50×4×5×3	0	0.96	1	1	1	1 163	2 586	755	1 701	1 379
32	50×4×5×5	0	0.98	1	1	1	641	1 436	423	950	755
33	50×8×3×3	0	0.94	1	1	1	1 102	2 467	746	1 677	1 290
34	50×8×3×5	0.03	0.95	1	1	1	897	2 043	628	1 399	1 045
35	50×8×5×3	0.06	0.93	1	1	1	2 227	5 012	1 560	3 472	2 611
36	50×8×5×5	0.01	0.96	1	1	1	2 509	5 704	1 797	3 981	2 745
