基于多策略多目标差分进化算法的风光储系统协调优化调度

doi:10.16182/j.issn1004731x.joss.23-1216

摘要/Abstract

摘要：

新能源发电单元的引入，使得电力系统组成结构愈发复杂，现有经济调度求解方法遇到诸多挑战。构建了一个风光储系统协调动态经济调度模型，给出了一种利用修补策略的约束条件处理 方法，提出了一种基于竞争机制的多策略多目标差分进化算法（competitive partitioning-based multi-strategy multi-objective differential evolutionary algorithm，CMMODE）。利用竞争机制将种群分区，并根据分区结果构建多个差分变异算子，以此生成多策略方案；采用精英自探索机制令种群具有跳出局部最优能力与局部开发能力。仿真实验验证了CMMODE算法在解决动态经济调度问题上的有效性，约束处理方法具有良好的可行性。

关键词: 差分进化算法, 竞争机制, 多策略方案, 约束处理, 动态经济调度

Abstract:

The introduction of new energy generation units makes the power system structure more and more complex, and the existing economic dispatching methods face many challenges. A coordinated and optimal dispatching for wind-photovoltaic-storage systems is constructed and a constraint handling method is given, a competitive mechanism-based multi-strategy multi-objective differential evolutionary(CMMODE) algorithm is proposed. The CMMODE algorithm utilizes a competitive mechanism to partition the population and constructs multiple differential variance operators based on the partitioning results, thus generating a multi-strategy scheme, employs an elite self-exploration mechanism to make the population have the ability to jump out of the local optimum and the ability of exploitation. The results show the effectiveness of the CMMODE algorithm in solving the dynamic economic dispatch problem, and the constraint processing method has good feasibility.

Key words: differential evolution algorithms, competitive mechanisms, multi-strategy schemes, constraint processing, dynamic economic dispatch
