高斯混沌火鹰优化算法求解动态优化问题的研究及应用

doi:10.16182/j.issn1004731x.joss.23-1128

摘要/Abstract

摘要：

在化学工业上有许多重要的化学过程依赖于动态优化，存在非线性与不连续性等因素，为寻找更高效的求解算法，在火鹰优化算法的基础上提出高斯混沌火鹰优化算法，在将控制变量参数化后用该算法求解此类问题。使用tent混沌映射替换原来的初始化种群方式，以使算法的最初分布更具合理性；在分析在火鹰位置更新、猎物位置更新后引入了竞争协同捕猎和逃避效应权重，提升了算法的开发和探索能力，同时还嵌入了高斯采样提高了种群的多样性，进一步增强了算法局部寻优和动态适应能力。仿真结果证明了算法在求解化工动态优化问题的有效性。

关键词: 化工动态优化, 高斯采样, 控制变量参数化, 混沌映射, 火鹰优化

Abstract:

There are many important chemical processes in the chemical industry rely on dynamic optimization with factors such as nonlinearity and discontinuity. In order to find a more efficient solution algorithm, Gaussian Chaotic fire hawk optimization algorithm is proposed based on the fire hawk optimization algorithm, which is used to solve such problems after parameterizing the control variables. The original way of initializing the populations is replaced using tent chaotic mapping in order to make more sense of the initial distribution of the algorithm; a more targeted update method has been proposed in the analysis of fire hawk location updates and prey location updates, enhancing the ability to develop and explore algorithms, Gaussian sampling is also embedded to improve the diversity of the population, further enhancing the algorithm's local search and dynamic adaptation capabilities. The results show the effectiveness of the algorithm in solving chemical dynamic optimization problems.

Key words: chemical dynamic optimization, Gauss sampling, control variable parameterization, chaotic mapping, fire hawk optimization algorithm

中图分类号:

TQ021.8

陈泳璋,莫愿斌 . 高斯混沌火鹰优化算法求解动态优化问题的研究及应用[J]. 系统仿真学报, 2025, 37(2): 436-449.

Chen Yongzhang,Mo Yuanbin . Gaussian Chaotic Fire Hawk Optimization Algorithm for Solving Dynamic Optimization Problems[J]. Journal of System Simulation, 2025, 37(2): 436-449.

图/表 16

图1

图2

图3

图4

表1

基准测试函数

函数	名称	解空间	最优解
F1	Sphere	[-100, 100]	0
F2	Schwefel 1.2	[-100, 100]	0
F3	Step	[-100, 100]	0
F4	Rastrigin	[-5.12, 5.12]	0
F5	Ackley	[-32, 32]	0
F6	Griewank	[-600, 600]	0
F7	Penalized 1	[-50, 50]	0
F8	Penalized 2	[-50, 50]	0
F9	Hartman 2	$[0,1]$	-3.32

表1

表2

算法参数设置

算法	参数设置
GCFHO	$c 1$ 、 $c 3 = 3$ ， $c 2$ 、 $c 4 = 2$
HHO	$E ∈ (- 1,1)$
PFA	$u 1$ 、 $u 2 ∈ [- 1,1]$

表2

表3

测试函数仿真结果

函数	指标	GCFHO	FHO	WOA	HHO	PFA	GWO
F1	最小值	1.416 2×10^-240	1.221 8×10^-143	3.263 7×10^-172	4.257 4×10^-215	1.614 1×10^-28	3.054 4×10^-61
	最大值	9.102 8×10^-227	2.347 4×10^-129	2.227 9×10^-152	5.157 3×10^-189	2.410 1×10^-25	5.336 2×10^-58
	均值	9.409 2×10^-228	1.915 7×10^-130	1.128 9×10^-153	5.045 1×10^-190	2.899 3×10^-26	6.214 6×10^-59
	标准差	0	6.020 7×10^-130	4.978 5×10^-153	0	5.574 4×10^-26	1.315 4×10^-58
F2	最小值	1.416 2×10^-240	1.221 8×10^-143	3.263 7×10^-172	4.257 4×10^-215	1.614 1×10^-28	3.054 4×10^-61
	最大值	9.102 8×10^-227	2.347 4×10^-129	2.227 9×10^-152	5.157 3×10^-189	2.410 1×10^-25	5.336 2×10^-58
	均值	9.409 2×10^-228	1.915 7×10^-130	1.128 9×10^-153	5.045 1×10^-190	2.899 3×10^-26	6.214 6×10^-59
	标准差	0	6.020 7×10^-130	4.978 5×10^-153	0	5.574 4×10^-26	1.315 4×10^-58
F3	最小值	0	0.011 5	0.010 3	9.921 92×10^-8	4.084 28×10^-6	2.240 73×10^-5
	最大值	0	6.792 4	0.354 0	0.000 5	1.762 4×10^-5	1.752 2
	均值	0	4.715 3	0.064 8	6.340 37×10^-5	9.447 59×10^-6	0.718 2
	标准差	0	2.120 6	0.079 4	0.000 1	3.484 66×10^-6	0.441 8
F4	最小值	0	0	0	0	45.989 3	0
	最大值	0	0	5.684 34×10^-14	0	143.143 2	1.136 87×10^-13
	均值	0	0	2.842 17×10^-15	0	80.350 5	8.526 51×10^-15
	标准差	0	0	1.271 06×10^-14	0	25.358 2	2.781 69×10^-14
F5	最小值	4.440 89×10^-16	4.440 89×10^-16	4.440 89×10^-16	4.440 89×10^-16	6.794 56×10^-14	1.465 49×10^-14
	最大值	4.440 89×10^-16	4.440 89×10^-16	7.549 52×10^-15	4.440 89×10^-16	3.521 0	2.176 04×10^-14
	均值	4.440 89×10^-16	4.440 89×10^-16	3.286 26×10^-15	4.440 89×10^-16	2.011 3	1.518 79×10^-14
	标准差	0	0	2.472 16×10^-15	0	0.944 0	1.738 56×10^-15
F6	最小值	0	0	0	0	0	0
	最大值	0	0	0.107 2	0	0.041 7	0.045 5
	均值	0	0	0.005 4	0	0.010 7	0.005 9
	标准差	0	0	0.024 0	0	0.011 6	0.013 3
F7	最小值	1.570 54×10^-32	0.000 1	0.001 1	2.293 89×10^-9	9.966 35×10^-7	0.012 4
	最大值	1.570 54×10^-32	0.301 0	1.265 2	9.377 16×10^-6	8.112 3	0.071 6
	均值	1.570 54×10^-32	0.044 9	0.067 3	2.677 63×10^-6	2.566 2	0.037 4
	标准差	2.808 01×10^-48	0.091 8	0.282 0	2.626 97×10^-6	2.792 4	0.016 0
F8	最小值	1.349 78×10^-32	0.015 2	0.024 7	3.777 41×10^-7	4.727 4×10^-6	0.170 3
	最大值	1.217 75×10^-7	2.998 7	0.710 4	0.000 1	0.233 4	1.123 2
	均值	6.088 75×10^-9	1.694 8	0.233 1	1.500 92×10^-5	0.035 8	0.554 6
	标准差	2.722 97×10^-8	1.384 1	0.189 4	3.216 06×10^-5	0.071 6	0.243 9
F9	最小值	-3.322 0	-3.308 2	-3.322 0	-3.293 6	-3.322 0	-3.322 0
	最大值	-3.203 1	-3.012 4	-2.873 4	-2.800 2	-3.203 1	-3.136 9
	均值	-3.298 2	-3.240 4	-3.235 6	-3.141 1	-3.268 5	-3.225 5
	标准差	0.048 8	0.091 3	0.126 0	0.124 0	0.060 7	0.069 0

表3

图5

表4

图6

图7

表5

图8

图9

图10

表6

参考文献 21

1	Sundaralingam Ramasubramanian. Two-step Method for Dynamic Optimization of Inequality State Constrained Systems Using Iterative Dynamic Programming[J]. Industrial & Engineering Chemistry Research, 2015, 54(31): 7658-7667.
2	Nocedal J, Wright S J. Numerical Optimization[M]. New York: Springer, 1999.
3	Eva Balsa Canto, Banga Julio R, Alonso Antonio A, et al. Restricted Second Order Information for the Solution of Optimal Control Problems Using Control Vector Parameterization[J]. Journal of Process Control, 2002, 12(2): 243-255.
4	Luus R. Iterative Dynamic Programming[M]. New York: CRC Press, 2019.
5	Zhou You, Liu Xinggao. Control Parameterization-Based Adaptive Particle Swarm Approach for Solving Chemical Dynamic Optimization Problems[J]. Chemical Engineering & Technology, 2014, 37(4): 692-702.
6	Liu Rui, Mo Yuanbin, Lu Yanyue, et al. Swarm-intelligence Optimization Method for Dynamic Optimization Problem[J]. Mathematics, 2022, 10(11): 1803.
7	Tian Jing, Zhang Panpan, Wang Yalin, et al. Control Vector Parameterization-based Adaptive Invasive Weed Optimization for Dynamic Processes[J]. Chemical Engineering & Technology, 2018, 41(5): 964-974.
8	Chen Xu, Du Wenli, Tianfield H, et al. Dynamic Optimization of Industrial Processes with Nonuniform Discretization-based Control Vector Parameterization[J]. IEEE Transactions on Automation Science and Engineering, 2014, 11(4): 1289-1299.
9	Lopez Cruz I L, Van Willigenburg L G, Van Straten G. Efficient Differential Evolution Algorithms for Multimodal Optimal Control Problems[J]. Applied Soft Computing, 2003, 3(2): 97-122.
10	Dadebo S A, Mcauley K B. Dynamic Optimization of Constrained Chemical Engineering Problems Using Dynamic Programming[J]. Computers & Chemical Engineering, 1995, 19(5): 513-525.
11	Xu Le, Mo Yuanbin, Lu Yanyue, et al. Improved Seagull Optimization Algorithm Combined with an Unequal Division Method to Solve Dynamic Optimization Problems[J]. Processes, 2021, 9(6): 1037.
12	Sun D Y, Lin Pimin, Lin Shuping. Integrating Controlled Random Search into the Line-up Competition Algorithm to Solve Unsteady Operation Problems[J]. Industrial & Engineering Chemistry Research, 2008, 47(22): 8869-8887.
13	Chen Xu, Mei Congli, Xu Bin, et al. Quadratic Interpolation Based Teaching-learning-based Optimization for Chemical Dynamic System Optimization[J]. Knowledge-Based Systems, 2018, 145: 250-263.
14	Azizi Mahdi, Talatahari Siamak, Gandomi A H. Fire Hawk Optimizer: A Novel Metaheuristic Algorithm[J]. Artificial Intelligence Review, 2023, 56(1): 287-363.
15	刘景森, 袁蒙蒙, 李煜. 基于改进樽海鞘群算法求解工程优化设计问题[J]. 系统仿真学报, 2021, 33(4): 854-866.
	Liu Jingsen, Yuan Mengmeng, Li Yu. Solving Engineering Optimization Design Problems Based on Improved Salp Swarm Algorithm[J]. Journal of System Simulation, 2021, 33(4): 854-866.
16	彭鑫, 祁荣宾, 杜文莉, 等. 一种改进的知识进化算法及其在化工动态优化中的应用[J]. 化工学报, 2012, 63(3): 841-850.
	Peng Xin, Qi Rongbin, Du Wenli, et al. An Improved Knowledge Evolution Algorithm and Its Application to Chemical Process Dynamic Optimization[J]. CIESC Journal, 2012, 63(3): 841-850.
17	Yucheng Lü, Mo Yuanbin, Lu Yanyue, et al. Enhanced Beetle Antennae Algorithm for Chemical Dynamic Optimization Problems' Non-fixed Points Discrete Solution[J]. Processes, 2022, 10(1): 148.
18	刘宗其, 杜文莉, 祁荣宾, 等. 基于知识改进的文化算法及其在化工动态优化中的应用[J]. 化工学报, 2010, 61(11): 2889-2895.
	Liu Zongqi, Du Wenli, Qi Rongbin, et al. Dynamic Optimization in Chemical Processes Using Improved Knowledge-based Cultural Algorithm[J]. CIESC Journal, 2010, 61(11): 2889-2895.
19	Angira Rakesh, Santosh Alladwar. Optimization of Dynamic Systems: A Trigonometric Differential Evolution Approach[J]. Computers & Chemical Engineering, 2007, 31(9): 1055-1063.
20	李国栋. 基于控制向量参数化的动态优化研究[D]. 杭州: 浙江大学, 2015.
	Li Guodong. Control Vector Parameterization Based Dynamic Optimization Research[D]. Hangzhou: Zhejiang University, 2015.
21	Luus R. Optimal Control by Dynamic Programming Using Systematic Reduction in Grid Size[J]. International Journal of Control, 1990, 51(5): 995-1013.

方法	维度	最优	最差	均值	标准差	时间/s
ADIWO^[7]	60	0.610 792	0.610 792	0.610 792	—	188
IDP^[10]	80	0.610 775	—	—	—	—
ISOA^[11]	30	0.610 592 23	—	—	—	272
APSO^[16]	100	0.610 785 0	0.610 785 0	0.610 785 0	—	—
EBSO^[17]	80	0.610 781 14	—	—	—	—
IKBCA^[18]	100	0.610 787	0.610 779	—	—	—
FHO	50	0.606 440 5	0.605 946 5	0.606 056 3	0.000 166 017	93
GCFHO	50	0.610 708	0.610 708	0.610 708	4.431 25×10^-8	34
	100	0.610 792	0.610 792	0.610 792	4.330 03×10^-9	225
	150	0.610 796	0.610 796	0.610 796	3.230 19×10^-8	551

方法	维度	最优	最差	均值	标准差	时间/s
HGPSO^[8]	10	0.477 71^*	0.477 71	0.477 71	—	9 641
IDP^[10]	40	0.476 95	—	—	—	—
ISOA^[11]	40	4.777 0	—	—	—	285
EBSO^[17]	40	0.476 972 8
IKBCA^[18]	100	0.477 70	0.477 68	—	—	—
TDE^[20]	40	0.476 946	—	—	—	—
FHO	90	0.473 434	0.471 652	0.472 330	0.000 527 142	165
	50	0.477 262	0.477 262	0.477 262	5.730 68×10^-8	35
GCFHO	90	0.477 711	0.477 711	0.477 711	2.441 65×10^-8	237
	120	0.477 688	0.477 687	0.477 687	6.080 86×10^-7	294

方法	维度	最优	最差	均值	标准差	时间/s
HGPSO^[8]	15	0.133 47	0.133 98	0.133 66	—	21 158
DE^[9]	13	0.135 580	0.244 612	0.146 501	0.033 552 999	674
LCA^[12]	20	0.133 18	0.201 02	0.147 142 5	0.024 088 327	—
QITLBO^[13]	20	0.133 11^*	0.133 14	0.133 20	2.39×10^-5	461
文献[21]	78	0.133 21	—	—	—	—
FHO	100	0.149 918	0.159 827	0.153 750	0.003 040 983	198
GCFHO	50	0.133 27	0.133 27	0.133 27	2.543 26×10^-11	53
	100	0.133 14	0.133 14	0.133 14	1.280 38×10^-8	235
	156	0.133 11	0.133 12	0.133 11	1.883 85×10^-6	492
