基于动态仿真与强化学习的化工装置调控研究

doi:10.16182/j.issn1004731x.joss.26-0140

摘要/Abstract

摘要：

针对蓄热式热力氧化炉（regenerative thermal oxidizer， RTO）在实际中废气浓度与气量波动以及工况变化使系统运行参数难以保持在经济最优区间，提出了一种基于强化学习的面向RTO运行控制的离线训练与现场部署相结合的智能控制策略框架。在离线阶段利用强化学习实现控制策略的自主学习与全局优化；在在线阶段，引入基于实时数据的策略自适应修正机制。将强化学习控制策略与运行监控与可视化系统集成，实现运行状态与控制效果的直观呈现。仿真结果表明：该单位蒸汽CO₂排放降低约1.4%，6个月运行周期内累计经济收益提升0.83%。在实际工业条件下系统蒸汽产出提升5.18%。

关键词: 蓄热式热力氧化炉, 强化学习, 动态仿真, 智能控制, 离线训练与现场部署

Abstract:

An intelligent control strategy framework combining offline training and on-site deployment for regenerative thermal oxidizer (RTO) operation control based on RL is proposed to solve the problem that fluctuations in exhaust gas concentration and flow, as well as changes in working conditions, make it difficult for RTO to maintain the system operating parameters within the economically optimal range in practical applications. In the offline phase, RL is employed to enable autonomous policy learning and global optimization. In the online phase, an adaptive policy correction mechanism based on real-time data is introduced. RL control strategy is integrated with the operation monitoring and visualization system to intuitively present operational status and control effects. Simulation results demonstrate that the CO₂ emissions per unit of steam are reduced by approximately 1.4%, and the cumulative economic benefit over a six-month operation period is increased by 0.83%. The steam production is increased by 5.18% in actual industrial conditions.

Key words: regenerative thermal oxidizer, reinforcement learning, dynamic simulation, intelligent control, offline training and on-site deployment

中图分类号:

TP391

李雨新,李海杰,韩尚伯等 . 基于动态仿真与强化学习的化工装置调控研究[J]. 系统仿真学报, 2026, 38(10): 2802-2818.

Li Yuxin,Li Haijie,Han Shangbo,et al . Chemical Plant Control Based on Dynamic Simulation and Reinforcement Learning[J]. Journal of System Simulation, 2026, 38(10): 2802-2818.
