切换忆阻神经网络的建模、动力学分析与实现

doi:10.16182/j.issn1004731x.joss.25-1025

摘要/Abstract

摘要：

为模拟生物大脑神经网络的动态功能切换机制，提出了四维时序切换忆阻Hopfield神经网络(time-switched memristive Hopfield neural network, TSM-HNN)模型。该模型以标准Hopfield神经网络为基础，引入并联忆阻器作为突触，并构建了其数学模型。通过外部时序信号的选择性激活，模型能够在不改变拓扑结构的前提下，实现对系统非线性动力学特性的动态调控。TSM-HNN单一系统在连续演化过程中，能生成数量和形态均不相同的多涡卷混沌吸引子，突破了传统混沌系统只能产生单一类型吸引子的局限。研究揭示了系统复杂的混沌行为、对初始条件的高度敏感性，并发现了由初始偏移增强的共存吸引子及同质多稳定性。通过PSPice平台进行了硬件电路设计与仿真，实验结果验证了所提模型的物理可行性。研究表明，忆阻突触的时序切换能够有效增强系统的随机性与复杂性，该模型在混沌加密与安全通信等领域具备潜在的应用价值。

关键词: 忆阻器, Hopfield神经网络, 时序切换, 多涡卷混沌吸引子, 多稳态性

Abstract:

To simulate the dynamic functional switching of brain networks, a time-switched memristive Hopfield neural network (TSM-HNN) model is proposed. The model utilizes external time-sequential signals to control memristive synapses, allowing it to dynamically generate multi-scroll chaotic attractors of varying numbers and morphologies without altering the system's structure. This overcomes the limitation of traditional chaotic systems, which can typically only produce a single type of attractor. The model exhibits complex chaotic behavior, high sensitivity to initial conditions, and coexisting attractors. Its physical feasibility has been verified through PSPice circuit simulations. This enhanced complexity and randomness give the model significant potential for applications in fields such as chaotic encryption and secure communication.

Key words: memristor, Hopfield neural network, time-switched, multi-scroll chaotic attractor, multistability

中图分类号:

TP391.9

瞿壮,张绍华,王聪等 . 切换忆阻神经网络的建模、动力学分析与实现[J]. 系统仿真学报, 2026, 38(9): 2590-2606.

Qu Zhuang,Zhang Shaohua,Wang Cong,et al . Modeling, Dynamical Analysis, and lmplementation of switched Memristive Neural Networks[J]. Journal of System Simulation, 2026, 38(9): 2590-2606.
