基于改进DBSCAN和距离共识评估的分段点云去噪方法

doi:10.16182/j.issn1004731x.joss.24-0153

摘要/Abstract

摘要：

针对点云数据中噪声点的剔除问题，提出了一种基于改进DBSCAN(density-based spatial clustering of applications with noise)算法的多尺度点云去噪方法。应用统计滤波对孤立离群点进行预筛选，去除点云中的大尺度噪声；对DBSCAN算法进行优化，减少算法时间复杂度和实现参数的自适应调整，以此将点云分为正常簇、疑似簇及异常簇，并立即去除异常簇；利用距离共识评估法对疑似簇进行精细判定，通过计算疑似点与其最近的正常点拟合表面之间的距离，判定其是否为异常，有效保持了数据的关键特征和模型敏感度。利用该方法对两个船体分段点云进行去噪，并与其他去噪算法进行对比，结果表明，该方法在去噪效率和特征保持方面具有优势，精确地保留了点云数据的几何特性。

关键词: 点云去噪, 点云数据, DBSCAN(density-based spatial clustering of applications with noise)聚类, 距离共识评估, 特征保持

Abstract:

A denoising method based on the improved DBSCAN(density-based spatial clustering of applications with noise) algorithm is proposed to address the problem of removing noise points in point cloud data. The statistical filtering method is applied to pre-screen isolated outliers and remove large-scale noise from the point cloud. The DBSCAN algorithm is optimized to reduce computational time complexity and achieve adaptive parameter adjustment, thereby dividing the point cloud into normal clusters, suspected clusters and abnormal clusters, and immediately removing abnormal clusters. Distance consensus assessment is applied, and suspect clusters are further evaluated. By calculating the distance between the suspected point and its nearest normal point fitting surface, it is determined whether the suspected point is abnormal, effectively maintaining the key features of the data and model sensitivity. This approach outperforms other algorithms in denoising efficiency and feature retention by being implemented on hull point clouds, which ensures the integrity of the point cloud data's geometric properties.

Key words: point cloud denoising, point cloud data, DBSCAN(density-based spatial clustering of applications with noise) clustering, distance consensus assessment, feature preservation

中图分类号:

TP391.9

葛程鹏,赵东,王蕊等 . 基于改进DBSCAN和距离共识评估的分段点云去噪方法[J]. 系统仿真学报, 2024, 36(8): 1800-1809.

Ge Chengpeng,Zhao Dong,Wang Rui,et al . Section Point Cloud Denoising Method Based on Enhanced DBSCAN and Distance Consensus Evaluation[J]. Journal of System Simulation, 2024, 36(8): 1800-1809.

图/表 17

图1

图2

表1

图3

图4

图5

图6

图7

图8

图9

表2

图10

图11

图12

表3

表4

参考文献 17

1	陈俊发, 黄港, 陈国仁. 基于三维激光扫描的船舶测量技术[J]. 中国修船, 2020, 33(3): 22-24.
	Chen Junfa, Huang Gang, Chen Guoren. Ship Measurement Technology Based on 3D Laser Scanning[J]. China Shiprepair, 2020, 33(3): 22-24.
2	陈俊发, 罗东浩. 三维激光扫描技术在船舶行业的应用[J]. 广东造船, 2018, 37(4): 68-70, 77.
	Chen Junfa, Luo Donghao. Application of 3D Laser Scanning Technology in Ship Engineering[J]. Guangdong Shipbuilding, 2018, 37(4): 68-70, 77.
3	杨荣淇, 胡敏捷. 基于海量点云的船舶型线快速确定方法研究[J]. 船舶设计通讯, 2018(2): 101-105.
	Yang Rongqi, Hu Minjie. Rapid Modeling Method of Ship Lines Based on Massive Point Cloud[J]. Journal of Ship Design, 2018(2): 101-105.
4	Sun Yujing, Schaefer S, Wang Wenping. Denoising Point Sets via L₀ Minimization[J]. Computer Aided Geometric Design, 2015, 35-36: 2-15.
5	Mattei E, Castrodad A. Point Cloud Denoising via Moving RPCA[J]. Computer Graphics Forum, 2017, 36(8): 123-137.
6	卢钰仁, 张明路, 吕晓玲, 等. 基于法向修正的双边滤波点云去噪处理[J]. 仪表技术与传感器, 2018(7): 111-115.
	Lu Yuren, Zhang Minglu, Xiaoling Lü, et al. Point Cloud Denoising Based on Normal Modification and Bilateral Filtering Processing[J]. Instrument Technique and Sensor, 2018(7): 111-115.
7	范晨, 金永, 刘静静, 等. 装配面点云特征增强的去噪算法研究[J]. 机械与电子, 2022, 40(2): 13-17.
	Fan Chen, Jin Yong, Liu Jingjing, et al. Research on Denoising Algorithm for Reature Enhancement of Assembly Surface Point Cloud[J]. Machinery & Electronics, 2022, 40(2): 13-17.
8	Hu Wei, Gao Xiang, Cheung Gene, et al. Feature Graph Learning for 3D Point Cloud Denoising[J]. IEEE Transactions on Signal Processing, 2020, 68: 2841-2856.
9	郭进, 陈小宁, 吕峻闽, 等. 采用密度k-means和改进双边滤波的点云自适应去噪算法[J]. 传感器与微系统, 2016, 35(7): 147-149, 153.
	Guo Jin, Chen Xiaoning, Junmin Lü, et al. Points Cloud Self-adaptive Denoising Algorithm Based on Density K-means and Improved Bilateral Fitering[J]. Transducer and Microsystem Technologies, 2016, 35(7): 147-149, 153.
10	Zeng Jin, Cheung Gene, Ng Michael, et al. 3D Point Cloud Denoising Using Graph Laplacian Regularization of a Low Dimensional Manifold Model[J]. IEEE Transactions on Image Processing, 2020, 29: 3474-3489.
11	Muhammad Abeer Irfan, Magli Enrico. Exploiting Color for Graph-based 3D Point Cloud Denoising[J]. Journal of Visual Communication and Image Representation, 2021, 75: 103027.
12	徐志博, 刘永生, 户盼茹. 结合离群因子和K-means++聚类改进的点云去噪算法[J]. 信息技术与信息化, 2023(3): 21-24.
13	戴士杰, 东强, 季文彬, 等. 基于法向修正与位置滤波的散乱点云去噪算法[J]. 传感器与微系统, 2023, 42(2): 130-134.
	Dai Shijie, Dong Qiang, Ji Wenbin, et al. Denoising Algorithm for Scattered Point Clouds Based on Normal Correction and Position Filtering[J]. Transducer and Microsystem Technologies, 2023, 42(2): 130-134.
14	陈文龙, 时宏伟. 基于KD树改进的DBSCAN聚类算法[J]. 计算机系统应用, 2022, 31(2): 305-310.
	Chen Wenlong, Shi Hongwei. Improved DBSCAN Clustering Algorithm Based on KD Tree[J]. Computer Systems & Applications, 2022, 31(2): 305-310.
15	Shi Congming, Wei Bingtao, Wei Shoulin, et al. A Quantitative Discriminant Method of Elbow Point for the Optimal Number of Clusters in Clustering Algorithm[J]. EURASIP Journal on Wireless Communications and Networking, 2021, 2021(1): 31.
16	朱广堂, 叶珉吕. 基于曲率特征的点云去噪及定量评价方法研究[J]. 测绘通报, 2019(6): 105-108.
	Zhu Guangtang, Ye Minlü. Research on the Method of Point Cloud Denoising Based on Curvature Characteristics and Quantitative Evaluation[J]. Bulletin of Surveying and Mapping, 2019(6): 105-108.
17	苏本跃, 马金宇, 彭玉升, 等. 基于K-means聚类的RGBD点云去噪和精简算法[J]. 系统仿真学报, 2016, 28(10): 2329-2334, 2341.
	Su Benyue, Ma Jinyu, Peng Yusheng, et al. Algorithm for RGBD Point Cloud Denoising and Simplification Based on K-means Clustering[J]. Journal of System Simulation, 2016, 28(10): 2329-2334, 2341.

[1]	苏本跃, 马金宇, 彭玉升, 盛敏. 基于K-means聚类的RGBD点云去噪和精简算法[J]. 系统仿真学报, 2016, 28(10): 2329-2335.
[2]	胡丝兰, 周明全, 税午阳, 武仲科. 一种改进Ball Pivoting的散乱点云数据重建算法[J]. 系统仿真学报, 2015, 27(10): 2446-2452.
