基于数据生成模型的仿真样本点插补方法

doi:10.16182/j.issn1004731x.joss.22-0554

摘要/Abstract

摘要：

为解决插补的仿真样本点与真实样本点概率分布不一致的问题，提出了基于数据生成模型的仿真样本点插补方法。基于高斯混合模型构建真实样本点的数据生成模型，其对应的高斯混合模型构件数通过多模型融合的策略确定；利用在真实样本点上获得的数据生成模型插补所需的仿真样本点，其中数据生成模型的构件以及构件权重用于控制仿真样本点的生成方式。在20个多模多维混合分布上对新方法的可行性和有效性进行了验证，实验结果表明，与随机样本点插补、合成少类过采样技术及其两种最新的变体等4种方法相比，本文方法能够获得更具概率分布一致性的仿真样本点，证实该方法是一种合理的仿真样本点插补方法。

关键词: 仿真样本点插补, 数据生成模型, 高斯混合模型, 合成少类过采样技术, 概率分布一致

Abstract:

In order to solve the problem of inconsistent probability distribution between synthetic samples by imputation and real samples, a data generation model-based synthetic sample imputation (DGM-SSI) method is proposed. The data generation model of real samples is constructed based on the Gaussian mixture model, and the number of corresponding components of the Gaussian mixture model is determined by the multi-model fusion strategy. The synthetic samples required for model imputation are generated by using the data obtained from the real samples. Specifically, the components of the data generation model and their weights are used to control the generation of synthetic samples. The feasibility and effectiveness of the DGM-SSI method are verified on 20 multi-model and multi-dimensional mixed distributions. The experiment result shows that compared with random sample imputation, synthetic minority over-sampling technique (SMOTE), and its two latest variants, the proposed method can obtain synthetic samples with a more consistent probability distribution, which proves that this method is a reasonable synthetic sample imputation method.

Key words: synthetic sample imputation, data generation model, Gaussian mixture model, synthetic minority over-sampling technique, probability distribution consistency

中图分类号:

TP391.9

何玉林,陈佳琪,徐贺鹏等 . 基于数据生成模型的仿真样本点插补方法[J]. 系统仿真学报, 2023, 35(9): 1948-1964.

He Yulin,Chen Jiaqi,Xu Hepeng,et al . Data Generation Model-based Synthetic Sample Imputation Method[J]. Journal of System Simulation, 2023, 35(9): 1948-1964.

图/表 14

图1

图2

图3

图4

图5

图6

图7

图8

表1

基于高斯分布的10种分布上5种仿真样本插补方法的MMD对比

数据集	真实样本点个数	仿真样本点个数	DGM-SSI	RSI	SMOTE	SMOTE-D	k-means SMOTE
$f 1 x$	2 000	2 000	0.015 8±0.003 0	0.225 6±0.014 7	0.830 2±0.014 3	0.704 6±0.047 0	0.832 8±0.014 3
$f 2 x$	4 000	4 000	0.012 4±0.001 0	0.354 1±0.001 5	0.892 6±0.002 7	0.823 6±0.014 4	0.892 3±0.002 2
$f 3 x$	4 000	4 000	0.039 7±0.037 5	0.267 7±0.002 4	0.056 0±0.010 1	0.087 6±0.007 2	0.076 1±0.007 7
$f 4 x$	8 000	8 000	0.017 7±0.004 9	0.136 2±0.004 6	0.486 0±0.003 3	0.394 6±0.009 1	0.642 8±0.012 4
$f 5 x$	6 000	6 000	0.018 8±0.001 2	0.193 0±0.002 8	0.310 9±0.004 3	0.257 3±0.006 8	0.353 6±0.024 8
$f 6 x$	12 000	12 000	0.012 6±0.001 6	0.149 6±0.000 1	0.410 4±0.004 9	0.341 7±0.006 3	0.412 2±0.002 5
$f 7 x$	8 000	8 000	0.014 9±0.000 6	0.132 6±0.001 4	0.267 0±0.007 1	0.224 4±0.004 6	0.267 2±0.005 6
$f 8 x$	16 000	16 000	0.015 4±0.003 6	0.081 8±0.000 1	0.246 8±0.002 0	0.208 9±0.005 9	0.246 7±0.001 8
$f 9 x$	10 000	10 000	0.012 8±0.000 1	0.120 2±0.001 0	0.267 9±0.004 9	0.225 0±0.001 2	0.419 9±0.255 2
$f 10 x$	20 000	20 000	0.009 7±0.000 1	0.060 6±0.000 2	0.180 8±0.000 8	0.148 7±0.002 6	0.180 9±0.000 9

表1

表2

基于高斯分布的10种分布上5种仿真样本插补方法的KL散度对比

数据集	真实样本点个数	仿真样本点个数	DGM-SSI	RSI	SMOTE	SMOTE-D	k-means SMOTE
$f 1 x$	2 000	2 000	0.001 2±0.000 8	0.011 9±0.006 9	1.301 3±0.283 3	0.224 5±0.040 6	0.011 9±0.006 9
$f 2 x$	4 000	4 000	0.000 9±0.001 3	0.011 3±0.013 1	4.791 1±2.109 6	9.903 4±3.213 9	0.011 3±0.013 1
$f 3 x$	4 000	4 000	0.042 8±0.071 7	0.392 1±0.046 2	0.130 4±0.055 4	0.376 4±0.076 1	0.392 1±0.046 2
$f 4 x$	8 000	8 000	0.009 3±0.008 1	0.087 6±0.037 0	0.571 7±0.018 4	0.199 6±0.064 8	0.087 6±0.037 0
$f 5 x$	6 000	6 000	0.005 3±0.001 1	0.051 1±0.005 4	0.112 2±0.020 6	0.087 4±0.014 9	0.051 1±0.005 4
$f 6 x$	12 000	12 000	0.003 0±0.002 6	0.015 2±0.004 4	0.120 2±0.005 0	0.968 4±0.007 0	0.015 2±0.004 4
$f 7 x$	8 000	8 000	0.001 8±0.000 4	0.026 8±0.010 3	0.154 7±0.012 0	0.236 2±0.006 8	0.026 8±0.010 3
$f 8 x$	16 000	16 000	0.035 5±0.030 5	0.023 2±0.000 8	0.150 4±0.019 2	0.302 1±0.011 9	0.023 2±0.000 8
$f 9 x$	10 000	10 000	0.001 7±0.001 1	0.175 9±0.005 5	0.127 2±0.023 6	0.189 2±0.024 3	0.175 9±0.005 5
$f 10 x$	20 000	20 000	0.001 3±0.000 9	0.033 4±0.005 9	0.143 2±0.037 4	2.536 1±0.087 2	0.033 4±0.005 9

表2

表3

基于均匀分布的10种分布上5种仿真样本插补方法的MMD对比

数据集	真实样本点个数	仿真样本点个数	DGM-SSI	RSI	SMOTE	SMOTE-D	k-means SMOTE
$f 11 x$	2 000	2 000	0.014 3±0.007 2	0.225 9±0.010 6	0.020 4±0.006 5	0.148 6±0.013 4	0.251 8±0.010 4
$f 12 x$	4 000	4 000	0.009 8±0.003 3	0.274 6±0.004 3	0.011 2±0.004 0	0.114 9±0.008 3	0.317 2±0.011 0
$f 13 x$	4 000	4 000	0.011 4±0.002 7	0.417 7±0.003 0	0.013 1±0.004 3	0.100 9±0.002 7	0.170 2±0.003 3
$f 14 x$	8 000	8 000	0.008 0±0.001 7	0.382 8±0.001 6	0.012 0±0.003 1	0.171 9±0.004 5	0.428 0±0.049 2
$f 15 x$	6 000	6 000	0.009 3±0.002 6	0.472 7±0.001 0	0.010 9±0.004 0	0.134 3±0.003 0	0.418 9±0.007 6
$f 16 x$	12 000	12 000	0.007 8±0.002 0	0.354 9±0.000 7	0.009 4±0.001 7	0.117 7±0.002 9	0.586 8±0.004 4
$f 17 x$	8 000	8 000	0.009 4±0.003 2	0.431 1±0.000 5	0.010 9±0.002 8	0.145 4±0.003 5	0.351 1±0.009 6
$f 18 x$	16 000	16 000	0.006 4±0.001 4	0.506 3±0.000 3	0.007 5±0.001 8	0.209 7±0.001 6	0.564 5±0.001 9
$f 19 x$	10 000	10 000	0.006 7±0.001 5	0.632 8±0.000 4	0.008 2±0.002 1	0.203 0±0.002 5	0.774 5±0.007 0
$f 20 x$	20 000	20 000	0.006 3±0.001 3	0.328 9±0.000 6	0.007 2±0.001 0	0.078 3±0.002 0	0.350 6±0.029 9

表3

表4

基于均匀分布的10种分布上5种仿真样本插补方法的KL散度对比

数据集	真实样本点个数	仿真样本点个数	DGM-SSI	RSI	SMOTE	SMOTE-D	k-means SMOTE
$f 11 x$	2 000	2 000	0.029 6±0.004 3	0.055 0±0.008 2	0.077 2±0.008 5	3.505 0±0.913 1	0.281 5±0.024 1
$f 12 x$	4 000	4 000	0.017 8±0.001 5	0.091 3±0.006 6	0.031 1±0.002 9	0.232 0±0.032 5	0.831 6±0.204 7
$f 13 x$	4 000	4 000	0.078 8±0.004 4	0.110 2±0.035 8	0.140 6±0.007 2	1.628 3±0.108 4	0.259 1±0.040 5
$f 14 x$	8 000	8 000	0.062 6±0.002 5	0.292 3±0.043 1	0.084 0±0.003 9	1.641 0±0.161 4	1.073 5±0.265 2
$f 15 x$	6 000	6 000	0.147 1±0.002 7	0.227 6±0.047 0	0.257 1±0.007 9	1.882 2±0.252 5	0.772 9±0.043 4
$f 16 x$	12 000	12 000	0.150 4±0.004 2	0.235 6±0.077 4	0.200 8±0.005 3	1.690 6±0.135 9	2.810 4±0.081 9
$f 17 x$	8 000	8 000	0.222 4±0.004 3	0.362 6±0.160 1	0.362 5±0.013 0	2.085 5±0.191 6	1.210 4±0.032 6
$f 18 x$	16 000	16 000	0.188 9±0.007 3	0.388 7±0.138 8	0.231 2±0.006 0	2.276 8±0.109 6	1.970 0±0.068 4
$f 19 x$	10 000	10 000	0.254 1±0.005 4	0.492 0±0.280 3	0.422 6±0.016 3	2.104 5±0.167 5	7.501 7±2.246 1
$f 20 x$	20 000	20 000	0.339 2±0.006 1	0.479 6±0.055 9	0.439 6±0.009 3	1.418 0±0.056 7	5.222 6±3.551 1

表4

图9

图10
