病毒传播变异与人群交叉活动的相互影响及扩散模型研究

doi:10.16182/j.issn1004731x.joss.23-0478

摘要/Abstract

摘要：

针对当前人际传染病毒高发态势，综合考虑病毒传播变异的随机特征和人群交叉活动之间的相互影响，提出并设计了多智能体模拟仿真推演模型。将病毒个体的外在致病性、传染性特征和人群个体的外在活动、免疫特征进行量化，将病毒个体与人群个体之间的相互依存及对抗过程进行建模，通过模型推演大量病毒个体和人群个体的发展趋势和统计特征。通过实验分析揭示了单个病毒变异方向的随机性不影响病毒群体变异发展方向的确定性：即病毒群体的致病性强度不断降低直到稳定在低值区间内，病毒群体的传染性强度不断升高，直到稳定在较高的数值区间内。给出了影响病毒传播变异过程的关键外在参数，可为高致病性病毒早期防控提供政策建议。

关键词: 病毒传播模型, 多智能体仿真, 预防和控制策略, 流行病病毒特征发展趋势, 遗传变异

Abstract:

In view of the current high incidence of human-to-human infectious viruses, a multi-agent simulation and deduction model was proposed and designed based on the random characteristics of virus transmission variation and the influence of population crossover activity. The external pathogenicity and infectious characteristics of the virus and the external activities and immune characteristics of the human were quantified, and the interdependence and confrontation process between the virus and the human were modeled. The development trends and statistical characteristics of a large number of viruses and humans were deduced through the model. The experimental analysis reveals that the randomness of the variation direction of a single virus does not affect the certainty of the development direction of the virus population variation. In other words, the pathogenicity intensity of the virus population continues to decrease until it stabilizes in the low-value range, and the infectious intensity of the virus population continues to increase until it stabilizes in the high-value range. The key external parameters that affect the virus transmission variation process are given, which can provide policy recommendations for the early prevention and control of highly pathogenic viruses.

Key words: virus transmission model, multi-agent simulation, prevention and control strategies, development trend of epidemic virus characteristics, genetic variation

中图分类号:

TP391.9

于雷,朱喜绸,廖华明等 . 病毒传播变异与人群交叉活动的相互影响及扩散模型研究[J]. 系统仿真学报, 2024, 36(7): 1713-1728.

Yu Lei,Zhu Xichou,Liao Huaming,et al . Interaction Between Virus Transmission Variation and Population Crossover Activity and Diffusion Model[J]. Journal of System Simulation, 2024, 36(7): 1713-1728.

图/表 14

图1

表1

图2

图3

图4

图5

图6

图7

图8

图9

图10

图11

图12

图13

参考文献 28

1	Belser J A, Maines T R, Tumpey T M, et al. Influenza a Virus Transmission: Contributing Factors and Clinical Implications[J]. Expert Reviews in Molecular Medicine, 2010, 12: e39.
2	Yin John, McCaskill J S. Replication of Viruses in a Growing Plaque: A Reaction-diffusion Model[J]. Biophysical Journal, 1992, 61(6): 1540-1549.
3	Newman Mark. Networks: An Introduction[M]. Oxford: Oxford University Press, 2010.
4	Martcheva Maia. An Introduction to Mathematical Epidemiology[M]. Boston: Springer US, 2015: 9-12.
5	Ciupe S M, Ribeiro R M, Nelson P W, et al. Modeling the Mechanisms of Acute Hepatitis B Virus Infection[J]. Journal of Theoretical Biology, 2007, 247(1): 23-35.
6	Min Lequan, Su Yongmei, Kuang Yang. Mathematical Analysis of a Basic Virus Infection Model with Application to HBV Infection[J]. Rocky Mountain Journal of Mathematics, 2008, 38(5): 1573-1585.
7	Pang Jianhua, Cui Jingan, Zhou Xueyong. Dynamical Behavior of a Hepatitis B Virus Transmission Model with Vaccination[J]. Journal of Theoretical Biology, 2010, 265(4): 572-578.
8	Zhao Shoujun, Xu Zhiyi, Lu Ying. A Mathematical Model of Hepatitis B Virus Transmission and Its Application for Vaccination Strategy in China[J]. International Journal of Epidemiology, 2000, 29(4): 744-752.
9	Smith A M, Perelson A S. Influenza a Virus Infection Kinetics: Quantitative Data and Models[J]. WIREs Systems Biology and Medicine, 2011, 3(4): 429-445.
10	Hattaf Khalid, Yousfi Noura. Global Dynamics of a Delay Reaction-diffusion Model for Viral Infection with Specific Functional Response[J]. Computational and Applied Mathematics, 2015, 34(3): 807-818.
11	Bessonov Nikolai, Bocharov Gennady, Meyerhans Andreas, et al. Nonlocal Reaction-diffusion Model of Viral Evolution: Emergence of Virus Strains[J]. Mathematics, 2020, 8(1): 117.
12	Rezapour Shahram, Mohammadi Hakimeh, Jajarmi Amin. A New Mathematical Model for Zika Virus Transmission[J]. Advances in Difference Equations, 2020, 2020(1): 589.
13	Tiago Yuzo Miyaoka, Lenhart S, F C A Meyer João. Optimal Control of Vaccination in a Vector-borne Reaction-diffusion Model Applied to Zika Virus[J]. Journal of Mathematical Biology, 2019, 79(3): 1077-1104.
14	Fang Zhiming, Huang Zhongyi, Li Xiaolian, et al. How Many Infections of COVID-19 There Will be in the "Diamond Princess"-predicted by a Virus Transmission Model Based on the Simulation of Crowd Flow[EB/OL]. (2020-02-25) [2023-02-03]. .
15	Herlocher M L, Elias S, Truscon R, et al. Ferrets as a Transmission Model for Influenza: Sequence Changes in HA1 of Type A (H3N2) Virus[J]. The Journal of Infectious Diseases, 2001, 184(5): 542-546.
16	Belser J A, Barclay W, Barr I, et al. Ferrets as Models for Influenza Virus Transmission Studies and Pandemic Risk Assessments[J]. Emerging Infectious Diseases, 2018, 24(6): 965-971.
17	张文彤. 甲型流感病毒H3抗原进化及变异规律研究[D]. 上海: 复旦大学, 2005.
	Zhang Wentong. Research for H3 Antigenic Evolution and Variation Rule of Influenza a Virus[D]. Shanghai: Fudan University, 2005.
18	徐德刚, 徐戏阳, 苏志芳. 具有病毒变异的复杂网络SIVR疾病传播模型研究[C]//第27届中国控制与决策会议论文集(下册). 青岛: 《控制与决策》编辑部, 2015: 2173-2178.
19	董晶, 徐浩, 刘文瑾, 等. 无标度网络上具有病毒变异的SIAS传播模型[J]. 长江大学学报(自然科学版), 2019, 16(5): 116-120.
20	亢婷. 禽流感模型的动力学行为与最优控制研究[D]. 银川: 宁夏大学, 2020.
	Kang Ting. Dynamic Behavior and Optimal Control of Avian Influenza Models[D]. Yinchuan: Ningxia University, 2020.
21	张婕. 基于遗传算法的传染病传播动力学建模与分析[D]. 太原: 山西大学, 2020.
	Zhang Jie. Modeling and Analysis of Infectious Disease Transmission Dynamics Based on Genetic Algorithm[D]. Taiyuan: Shanxi University, 2020.
22	罗晓峰. 复杂网络上的传染病系统动力学建模分析与应用[D]. 太原: 山西大学, 2020.
	Luo Xiaofeng. System Dynamics Modelling Analysis and Application of Infectious Diseases in Networks[D]. Taiyuan: Shanxi University, 2020.
23	李稚, 宋敏. 基于"病毒变异"和"环境传人"因素的COVID-19疫情传播动力学研究[J]. 复杂系统与复杂性科学, 2021, 18(4): 1-8.
	Li Zhi, Song Min. Transmission Dynamics of Coronavirus Disease 2019 Based on "Virus Variants" and "Environment-to-human"[J]. Complex Systems and Complexity Science, 2021, 18(4): 1-8.
24	刘勇. 新冠流行期间广东地区流感流行特征及流行趋势预测研究[D]. 广州: 广州医科大学, 2022.
	Liu Yong. Epidemiological Characteristics and Trend Prediction of Influenza during the COVID-19 Epidemic in Guangdong Province[D]. Guangzhou: Guangzhou Medical University, 2022.
25	靳远. 甲型流感病毒重要亚型的进化研究[D]. 北京: 中国人民解放军军事医学科学院, 2015.
	Jin Yuan. Research on the Evolution of Major Subtypes in Influenza a Virus[D]. Beijing: Chinese People's Liberation Army Academy of Military Medical Sciences, 2015.
26	郑佳纯. 贝叶斯模型预测新型冠状病毒肺炎流行趋势的研究[D]. 汕头: 汕头大学, 2021.
	Zheng Jiachun. Approach on the Epidemic Trend of COVID-19 Based on Bayesian Model[D]. Shantou: Shantou University, 2021.
27	李海冰, 黄戈, 房志明, 等. 基于多层级人员流通的病毒传播模型[J]. 武汉理工大学学报(信息与管理工程版), 2023, 45(1): 13-20.
	Li Haibing, Huang Ge, Fang Zhiming, et al. Virus Transmission Model Based on Multi-level People Circulation[J]. Journal of Wuhan University of Technology(Information & Management Engineering), 2023, 45(1): 13-20.
28	刘程芳, 梁雨朝, 周健, 等. 基于感染力与免疫作用的新型冠状病毒肺炎疫情传播模型[J]. 生物化学与生物物理进展, 2022, 49(10): 1874-1888.
	Liu Chengfang, Liang Yuchao, Zhou Jian, et al. Transmission Model of COVID-19 Pandemic Based on Infectivity and Immunity[J]. Progress in Biochemistry and Biophysics, 2022, 49(10): 1874-1888.

infect_inten	概率分布/%
加1或减1	70
加2或减2	20
加3或减3	5
加4或减4	3
加5或减5	1
加6或减6	0.7
加7或减7	0.3
其他	0
